Jaw Crusher Manufacturer | High-Efficiency Stone Crushing Equipment
Powerful Jaw Crushers for Mining, Quarrying & Construction Projects
Looking for a reliable jaw crusher for your crushing plant?
Our heavy-duty jaw crushers are designed to crush granite, basalt, limestone, river pebbles, quartz, concrete waste, construction debris, and other hard rock materials with high efficiency and low operating costs.
With robust construction, high crushing ratios, and easy maintenance, our jaw crushers are trusted by customers in mining, quarrying, aggregate production, recycling, and infrastructure projects worldwide.
Applications
1. Mining Industry
Primary crushing of gold ore, copper ore, iron ore, and other minerals.
2. Quarry & Aggregate Production
Production of aggregates for concrete, asphalt, and road construction.
3. Construction Waste Recycling
Crushing concrete blocks, bricks, and demolition debris into reusable aggregates.
4. Infrastructure Projects
Supplying high-quality aggregates for highways, railways, airports, and dams.
Why Choose Us
Optimized crushing chamber design delivers greater throughput while reducing energy consumption.
Made from high-strength steel and premium wear-resistant components for long service life.
Available in both wheel-mounted and tracked configurations, making it suitable for various working environments including quarries, mines, urban construction sites, and remote projects.
Efficient power utilization and durable wear parts reduce maintenance expenses.
Simple structure enables quick inspection and replacement of key components.
Suitable for crushing granite, basalt, limestone, river pebbles, quartz, concrete waste, construction debris, and various hard rock materials.
Working Principle
The jaw crusher uses compressive force to break materials.
The movable jaw moves periodically toward the fixed jaw, crushing large rocks into smaller particles. When the movable jaw retracts, the crushed material exits through the discharge opening.
This simple yet efficient design ensures:
✓ High crushing capacity
✓ Stable performance
✓ Uniform product size
✓ Reliable operation
Technical Advantages
- Deep Crushing Chamber
Improves material flow and increases crushing efficiency.
- High Manganese Steel Jaw Plates
Provides excellent wear resistance and longer service life.
- Advanced Flywheel Design
Reduces vibration and improves machine stability.
- Strong Bearing System
Ensures continuous operation under heavy-duty conditions.
- Large Feed Opening
Allows processing of oversized materials directly from blasting or excavation.
Technical Specifications
| Model | Feed Opening (mm) | Max Feeding Size (mm) | Discharge Opening Range (mm) | Capacity (t/h) | Overall Dimensions (mm) |
|---|---|---|---|---|---|
| PE-250×400 | 250×400 | 210 | 20-60 | 5-21 | 1300×1090×1270 |
| PE-400×600 | 400×600 | 340 | 40-100 | 16-64 | 1730×1730×1630 |
| PE-500×750 | 500×750 | 425 | 50-100 | 40-110 | 1980×2080×1870 |
| PE-600×750 | 600×750 | 500 | 150-200 | 80-240 | 2070×2000×1920 |
| PE-600×900 | 600×900 | 500 | 65-160 | 50-160 | 2190×2206×2300 |
| PE-750×1060 | 750×1060 | 630 | 80-140 | 110-320 | 2600×2430×2800 |
| PE-800×1060 | 800×1060 | 640 | 130-190 | 130-320 | 2710×2430×2800 |
| PE-830×1060 | 830×1060 | 650 | 160-220 | 150-336 | 2740×2430×2800 |
| PE-870×1060 | 870×1060 | 660 | 200-260 | 190-336 | 2810×2430×2800 |
| PE-900×1060 | 900×1060 | 685 | 230-290 | 230-390 | 2870×2420×2940 |
| PE-900×1200 | 900×1200 | 750 | 95-165 | 220-380 | 3380×2870×3330 |
| PE-1000×1200 | 1000×1200 | 850 | 195-265 | 315-500 | 3480×2870×3330 |
| PE-1200×1500 | 1200×1500 | 1020 | 150-350 | 400-800 | 4200×3300×3500 |
| PE-1500×1800 | 1500×1800 | 1200 | 220-350 | 500-1000 | 5160×3660×4248 |
| PEX-150×750 | 150×750 | 120 | 18-48 | 8-25 | 1200×1530×1060 |
| PEX-250×750 | 250×750 | 210 | 25-60 | 13-35 | 1380×1750×1540 |
| PEX-250×1000 | 250×1000 | 210 | 25-60 | 16-52 | 1560×1950×1390 |
| PEX-250×1200 | 250×1200 | 210 | 25-60 | 20-61 | 2140×1660×1500 |
| PEX-300×1300 | 300×1300 | 250 | 20-90 | 16-105 | 2720×1950×1600 |
After-Sales Support
When you purchase from us, you receive comprehensive support:
- Equipment selection guidance
- Crushing plant design
- Installation assistance
- Operator training
- Spare parts supply
- Online technical support
- Lifetime after-sales service
Our engineering team helps ensure your project starts quickly and operates efficiently.
Project Cases
120t/h Granite Crusher in Uganda
A quarry customer in Uganda purchased our PE-600×900 jaw crusher for aggregate production. The crusher has been operating reliably with high crushing efficiency and low maintenance requirements, helping the customer produce quality aggregates for local road and infrastructure projects.
200t/h River Stone & Granite Crusher in Venezuela
A construction materials producer in Venezuela installed our PE-750×1060 jaw crusher as the primary crushing equipment in its aggregate production line. The machine delivers stable performance, high output, and consistent product quality, supporting local infrastructure and concrete production projects.
FAQ
The main parts include the fixed jaw, movable jaw, frame, eccentric shaft, flywheel, toggle plate, and jaw liners.
Key factors include material hardness, abrasiveness, feed size, feed rate, liner condition, and the crusher setting.
Maintenance includes inspection, lubrication, monitoring wear parts, checking belts and bearings, and replacing damaged components on time.
Yes. Jaw crushers are commonly used in mobile and compact crushing applications because they fit well in space-limited setups.
