Overview
JZC Climbing Bucket Concrete Mixer for Sale
The JZC Climbing Bucket Concrete Mixer is a diesel-powered concrete mixer designed for small and medium construction projects. Equipped with a climbing bucket feeding system, it can efficiently lift and feed materials into the mixing drum, reducing manual material handling and improving construction efficiency.
With a compact structure, reliable performance, and easy operation, the JZC climbing bucket concrete mixer is suitable for building construction, road construction, rural projects, concrete repair, and other small-scale construction sites.
Why Choose Us
The climbing bucket system automatically lifts sand, gravel, and other materials to the mixer, making feeding easier and reducing labor requirements.
The diesel-powered design allows the mixer to operate independently without relying on a stable electricity supply. It is suitable for construction sites in areas with limited or unstable power.
The JZC mixer has a simple operating structure and is easy for workers to learn and operate. It is designed for convenient daily use and maintenance.
The mixing drum provides efficient mixing of cement, sand, aggregate, and water to produce uniform concrete for various construction applications.
JZC climbing bucket concrete mixers are suitable for projects where a large stationary concrete batching plant is not necessary.
The compact structure makes the mixer suitable for construction sites with limited space. It can be moved between different working locations according to project requirements.
JZC Concrete Mixer Features
- Diesel engine powered
- Climbing bucket feeding system
- Compact structure
- Easy operation
- Easy maintenance
- Efficient material feeding
- Reliable concrete mixing
- Suitable for remote construction sites
- Suitable for small and medium projects
- Flexible construction applications
Application
The JZC mixer is widely used for concrete production at small and medium construction sites.
Typical applications include:
- Construction sites without reliable electricity
- Building construction
- Residential construction
- Rural construction projects
- Road construction
- Bridge construction
- Concrete floor construction
- Foundation construction
- Small infrastructure projects
- Concrete repair and maintenance
Working Principle
The JZC climbing bucket concrete mixer combines material loading, bucket lifting, and concrete mixing in one machine.
1. Load Materials
Load cement, sand, aggregate, and other materials into the feeding bucket.
2. Lift the Bucket
The climbing bucket automatically lifts the materials to the required feeding position.
3. Feed the Mixing Drum
The materials are discharged into the mixing drum for mixing.
4. Add Water
Add the required amount of water according to the concrete mix design.
5. Mix the Concrete
The mixing drum rotates to thoroughly mix the cement, aggregate, sand, and water.
6. Discharge Concrete
After mixing, the finished concrete can be discharged directly at the construction site.
Parameter
| Model Specification | JZC350B | JZC400B | JZC500B | JZC750B |
|---|---|---|---|---|
| Discharge Capacity (L) | 350 | 400 | 500 | 750 |
| Feed Capacity (L) | 560 | 640 | 800 | 1200 |
| Productivity (m³/h) | 10–14 | 12–16 | 18–20 | 25–30 |
| Stirring Motor Power (kW) | 5.5 | 5.5–7.5 | 7.5–11 | 11–15 |
| Lifting Motor Power (kW) | 4.5 | 4.5 | 5.5 | 7.5 |
| Water Pump Power (kW) | 0.55 | 0.55 | 0.75 | 1.1 |
| Water Supply Accuracy | Error ≤ 2% | Error ≤ 2% | Error ≤ 2% | Error ≤ 2% |
| Mixer Drum Speed (r/min) | 14 | 14 | 13 | 12 |
| Maximum Aggregate Particle Size (mm) | 40–60 | 40–60 | 60/80 (Gravel/Pebble) | 60/80 (Gravel/Pebble) |
| Maximum Drag Speed | 10–15 | 10–15 | 10–15 | 10–15 |
| Dimensions (L × W × H) (mm) | 2760 × 2170 × 3000 | 2940 × 2240 × 2880 | 3320 × 2460 × 3650 | 3810 × 2120 × 3730 |
| Machine Weight (kg) | 1950 | 2160 | 3100 | 4200 |
Specifications can be customized according to project requirements. Contact us for the latest technical specifications.
JZC Climbing Bucket Concrete Mixer vs. Ordinary Concrete Mixer
Compared with a conventional concrete mixer that requires manual feeding, the JZC climbing bucket model uses a mechanical bucket lifting system to improve material feeding efficiency.
| Feature | JZC Climbing Bucket Concrete Mixer | Ordinary Manual Feeding Mixer |
|---|---|---|
| Aggregate Feeding | Climbing bucket | Mainly manual |
| Labor Requirement | Lower | Higher |
| Power option | Diesel | Electric / Diesel |
| Material Loading | More convenient | More labor-intensive |
| Suitable for remote sites | Yes | Depends on power supply |
| Operation | Simple | Simple |
| Small project application | Yes | Yes |
| Construction Flexibility | High | Moderate |
The diesel-powered JZC concrete mixer is particularly suitable for construction projects in remote areas where electricity is unavailable or unstable.
The diesel engine provides an independent power source, while the climbing bucket helps reduce manual feeding work.
This makes the machine suitable for projects in Africa, Southeast Asia, the Middle East, Latin America, and other developing construction markets.
Project Cases
JZC Concrete Mixer in Ghana
A construction contractor in Ghana selected a JZC Tipping Bucket Concrete Mixer for local building and infrastructure projects. The tipping bucket feeding system improved aggregate loading efficiency and allowed the contractor to produce concrete conveniently at the construction site.
JZC Concrete Mixer in Nigeria
A construction contractor in Nigeria chose a JZC Tipping Bucket Concrete Mixer for on-site concrete production. With efficient tipping bucket feeding and reliable mixing performance, the mixer provides a practical solution for local building and infrastructure projects.
FAQ
The mixer can mix cement, sand, aggregate, water, and other concrete ingredients to produce concrete for construction projects.
The main difference is the mixing capacity. JZC500 has a larger mixing capacity than JZC300 and is suitable for projects requiring higher concrete output.
Yes. JZC concrete mixers can be equipped with diesel engines, making them suitable for construction sites without reliable electricity.
Send us your required model, quantity, destination country, and project requirements. We will provide a suitable model and quotation.
