JZC Diesel Concrete Mixer for Sale
JZC Diesel Concrete Mixer is a drum-type concrete mixer powered by a diesel engine, designed for flexible concrete production at construction sites, road projects, building projects and other locations without reliable electricity.
With a compact structure, easy operation and strong mobility, JZC diesel concrete mixers are suitable for small and medium-sized construction projects.
The JZC series diesel concrete mixer uses a rotating drum to mix cement, aggregates, sand and water into uniform concrete.
The diesel-powered design allows the mixer to work independently from the power grid, making it suitable for remote construction sites and areas with unstable electricity supply.
The mixer can be used for concrete production in residential construction, road construction, bridges, foundations and other projects.
Why Choose Us
The diesel engine provides an independent power source, allowing the mixer to operate in remote areas, temporary construction sites and locations with unreliable electricity.
JZC diesel concrete mixers are suitable for projects that require a flexible concrete mixing solution without installing a complete stationary batching plant.
The compact structure makes the mixer easier to move between construction areas, while the straightforward operating system helps reduce operator training requirements.
For projects with relatively small concrete requirements, a diesel concrete mixer can provide a more flexible solution compared with installing a complete concrete batching plant.
JZC Concrete Mixer Features
- Diesel engine powered – suitable for sites without stable electricity
- Strong mixing performance – produces consistent concrete mixtures
- Easy operation – simple controls for convenient daily use
- Compact design – suitable for limited construction sites
- Easy maintenance – accessible components simplify routine maintenance
- Flexible application – suitable for construction, roads, bridges and foundations
- Multiple models – different capacities are available for different project requirements
Application
JZC Diesel Concrete Mixer can be used for:
1. Building Construction
Suitable for foundations, floors, columns, walls and other concrete construction work.
2. Road Construction
Used for concrete mixing in road, pavement and drainage projects.
3. Bridge & Infrastructure Projects
Suitable for small and medium concrete requirements in bridge and infrastructure construction.
4. Rural & Remote Construction
The diesel engine makes the mixer suitable for areas where electricity is unavailable or unstable.
5. Small Concrete Projects
A practical solution for contractors who need on-site concrete mixing without a large batching plant.
Working Principle
The mixer combines cement, sand, aggregate and water inside the rotating drum.
1. Feeding
Cement, aggregates, sand and water are added into the mixing drum.
2. Mixing
The drum rotates continuously to mix the materials evenly.
3. Discharging
After mixing, the finished concrete is discharged from the drum.
4. Repeated Operation
The mixer can continuously produce batches of concrete according to project requirements.
Parameter
| Model Specification | JZC300 | JZC350 | JZC500 | JZC750 |
|---|---|---|---|---|
| Discharge Capacity (L) | 300 | 350 | 500 | 750 |
| Feed Capacity (L) | 480 | 560 | 800 | 1200 |
| Productivity (m³/h) | 9–11 | 10–14 | 15–20 | 20–25 |
| Diesel Engine Power (kW) | 8.4 | 11 | 13.2 | 14.5 |
| Water Pump Power (kW) | 0.55 | 0.55 | 0.75 | 0.75 |
| Water Supply Accuracy | Error ≤ 2% | Error ≤ 2% | Error ≤ 2% | Error ≤ 2% |
| Mixer Drum Speed (r/min) | 14 | 14 | 14 | 14 |
| Maximum Aggregate Particle Size (mm) | 60 | 60 | 60 | 60 |
| Maximum Drag Speed (km/h) | 10–15 | 10–15 | 10–15 | 10–15 |
| Dimensions (m) | 2.5 × 2.2 × 2.2 | 2.6 × 2.2 × 2.2 | 2.8 × 2.2 × 2.2 | 2.9 × 2.2 × 2.2 |
| Machine Weight (kg) | 1150 | 1300 | 1500 | 1650 |
Specifications can be customized according to project requirements. Contact us for the latest technical specifications.
Project Cases
JZC Concrete Mixer in Ghana
A construction contractor in Ghana selected a JZC Tipping Bucket Concrete Mixer for local building and infrastructure projects. The tipping bucket feeding system improved aggregate loading efficiency and allowed the contractor to produce concrete conveniently at the construction site.
JZC Concrete Mixer in Nigeria
A construction contractor in Nigeria chose a JZC Tipping Bucket Concrete Mixer for on-site concrete production. With efficient tipping bucket feeding and reliable mixing performance, the mixer provides a practical solution for local building and infrastructure projects.
FAQ
The mixer can mix cement, sand, aggregate, water, and other concrete ingredients to produce concrete for construction projects.
Yes. Its diesel engine provides an independent power source, making it suitable for remote construction sites and areas with unstable electricity.
Configuration can be discussed according to the customer’s project requirements, working conditions and destination market.
Send us your required model, quantity, destination country, and project requirements. We will provide a suitable model and quotation.
